Allen Cell Collection
AICS-0093
Protein
telomeric repeat-binding factor 2 (TRF2)
Gene Symbol
TERF2
Gene Name
telomeric repeat binding factor 2
Structure
telomeres
Certificate of AnalysishPSCreg Certificate

Obtain AICS-0093

Obtain Donor Plasmid

AICS-0093

TERF2 in WTC-mEGFP (mono-allelic tag)
Cell line media

Single, mid-level plane of cells in a live hiPS cell colony expressing mEGFP-tagged telomeric repeat-binding factor 2 (TRF2). Cells were imaged in 3D on a spinning-disk confocal microscope. Scale bar, 5 μm.

thumbnail image
thumbnail image
Video thumbnail
Video thumbnail
Video thumbnail
NCBI Isoforms:
crRNA Target Site:CGCTGTTTCTATCATGGCCG
Linker: SGRTQIP
Cas9:Wildtype spCas9
mEGFP Insert
mEGFP Insert
Top: TERF2 locus; Bottom: Zoom in on mEGFP insertion site at TERF2 N-terminal exon.
